B-400 Glass Engraving Machine

Introduction:B-400 Glass Engraving Machine

B-400 Glass Engraving Machine

Description		B-400(NO ATC)
Work Table	mm	570*500
Trave(X/Y/Z)	mm	400/400/160
X、Y、Z Positioning Accurancy	mm	0.01/0.01/0.008
X、Y、Z Repeating accurancy	mm	0.008/0.008/0.005
Max.Feed	m/min	12
Cutting Feed	m/min	6
Spindle Motor	Kw	3.7
Spindle speed	rpm	48000
Spindle Nose to table	mm	60-150
Distance between spindles	mm	10-170
Tool size	#	ER20
Tool change	#	Manual
Measurement compensation	#	Auto
Air supply	Mpa	≥0.6
Power supply	#	Three Phase 220V/50Hz
Power	Kw	5.5
Max.loading	Kg	100
Weight	Kg	1300
Dimension	mm	120011501650+300
