JIS L1096-2010 Water Vapour Permeability Tester

Introduction:JIS L1096-2010 Water Vapour Permeability Tester ±1℃ Shearing Thermal Test Chamber

Detail Information：

Internal Dimension:	(WDH) 10008001000mm	External Dimension:	(WDH) 150011801900mm
Test Condition:	20±20C; 65% RH	Temperature Accuracy:	±1℃
Humidity Range:	20~98%R.H. (Refer Image Below)	Cooling Method:	Air Cooling
High Light:	JIS L1096-2010 Water Vapour Permeability Tester , 65% RH Water Vapour Permeability Tester

Applications：

Test Standard：

Technical Parameters：

Technical Index	HD-E702-800-K40
Cooling speed	1℃/min in average (without loading)
Heating speed	3℃/min in average (without loading)
Internal chamber material	SUS#304 stainless steel, mirror finished
External chamber material	Stainless steel with paint spray
Controller	LCD touch screen, programmable control temperature and humidity Can set different parameter for cyclic test
Insulation material	50mm high density rigid Polyurethane foam
Heater	Explosion-proof type SUS#304 stainless steel fins radiator pipe heater
Compressor	France Tecumseh compressor
Lighting	Heat resistance
Temperature sensor	PT-100 dry and wet bulb sensor
Observation window	Tempered glass
Testing hole	Diameter 50mm, for cable routing
Power supply source	three-phase, 380V±10%, 50/60Hz
Gross Weight	500kg
Safety protection device	Protection for leakage Over-temperature Compressor overvoltage and overload Heater short circuit Water shortage
